MAD 6X12-II Coaxial Tuned Propulsion System M6C12 170KV Motor 60A FOC ESC 22″ Propeller For Heavy Payload UAV Drones

MAD 6X12-ll is a coaxial structure power system specially designed for a mult rotor UAV with a single axle load of 5-7kg. The max thrust can reach 15kg. The 6X12-ll power adopts an integrated power assembly, integrates M6C12 100KV Motor 60A FOC ESC and 22″ Propeller. lt focuses on optimizing its force efficiency, safety and endurance under extreme conditions. Therefore, it is great for industrial drones for mapping,aerial,inspection,firefighting,military,search and rescue and etc.
It is suitable for a multi rotor aircraft with a carbon tube diameter of 30mm.

Specifications:
Item Model: 6X12-ll coaxial power system
Max Thrust: 14800g / rotor @48v(sea level)
Recommend Take-off Weight: 5000g-7000g /rotor @48V(sea level)
Recommend voltage: 12S Lipo
Operating Temperature: -20~60℃
Unit Combo Weight: 1050g
Extension Wire Length: 710mm/780mm (Input/Signal Wires)
Compatible Carbon Tube: 30mm (25mm Conversion ring)

Propeller
Diameter / pitch: CB2 22×7.OIN ultralight PROP(558.8×177.8mm)
Unit Weight: 32g/pc

Motor
Stator Size: 64×12 mm
Unit Weight: 280g

FOC ESC
Max lInput voltage: 6OV
Max Continuous Current: 6OA
Max Throttle Signal Frequency: 500Hz
Recommend voltage: 6-14S
