SUNNYSKY V4008 KV380 KV600 High Efficiency Brushless Motor For Multi-Rotor Drones

SUNNYSKY V4008 KV380 KV600 High Efficiency Brushless Motor For Multi-Rotor Drones - Image 2

SUNNYSKY V4008 KV380 KV600 High Efficiency Brushless Motor For Multi-Rotor Drones - Image 3

SUNNYSKY V4008 KV380 KV600 High Efficiency Brushless Motor For Multi-Rotor Drones - Image 4

SUNNYSKY V4008 KV380 KV600 High Efficiency Brushless Motor For Multi-Rotor Drones - Image 5

SUNNYSKY V4008 KV380 KV600 High Efficiency Brushless Motor For Multi-Rotor Drones

Original price was: $64.99.Current price is: $45.49.

SKU: CMMTD 8305618667 Categories: Motor for Drones, MULTI-ROTORS

Multiple payment options for secure shopping with SSL
Have the best deals
The home of quality products.
Experience the difference quality makes.

PRODUCT DESCRIPTION

Sunnysky V series of motors are specially designed power for long-endurance multirotor aircraft. Designing style of the whole series are high efficiency, stable stable structure, light weight, high consistency etc.. Those motors can produce enough torque at low RPM and work at peak efficiency during flight.

Sunnysky V4008 340KV 600KV brushless motor is compatible with the 12″-15″ propellers, the max thrust can reach to 2440g. V4008 380KV brushless motor is suitable for 4-6S battery while the V4008 600KV one is suitable for 4S battery only. You can choose the proper one according to your own requirements.

Main Features:
1. SUNNYSKY V4008 series motors are designed for long flight time multirotors. These motors can produce enough torque at low RPM and work at peak efficiency during flight.

2. The whole series uses Sunnysky patented Stepped and knurled design that not only efficiently prevent motors from getting loose, but also reduce the probability of malfunction and unstable output power. The whole series use original Japanese EZO bearings that provide quiet and stable flight in the air.

3. With the guarantee of strength, the caps of V motors are highly hollow-cutted to save weight, so that these motors can reach maximum thrust-to-weight ratio and gain more flight time.

4. The Sunnysky V series motors are dynamically balanced with our hightest standard. The axial
and radial runouts of each rotor are tested strictly according to its design. The difference in performance of each motor is controlled within 3% so that these products can provide precise and stable power for professional applications.

Specifications:

Motor Model / KV	V4008/ KV380	V4008/ KV600
Stator/Rotor Poles	18N24P	18N24P
Internal resistance	131mΩ	75mΩ
Motor size	φ44.3*28.5mm	φ44.3*28.5mm
Shaft diameter	4.0mm	4.0mm
AWG	20AWG 600mm	20AWG 600mm
Motor weight(wire included)	105g	104g
Motor weight(wire excluded)	No data	No data
Rated operational voltage	4-6S	4S
No-load current	0.5A/10V	0.8A/10V
Maximum continuous power	500W	480W
Maximum continuous current	20A/30s	30A/30s
ESC recommended use	30-40A	40A
Propeller size recommended use	EOLO CN125/CN135/CN155.5/CN176.2	EOLO CN135/CN155.5

V4008 380KV Test Reports:

Prop(inch)	Voltage(V)	RPM	Amps(A)	Thrust(gf)	Watts(W)	Efficiency(g/W)	Load temperature in 100% throttle
EOLO CN12*5	22.2	2983	0.7	200	16	12.87	68℃
		3514	1.2	300	27	11.26
		4020	1.7	400	38	10.60
		4440	2.3	500	51	9.79
		4785	2.9	600	64	9.32
		5204	3.6	700	80	8.76
		5568	4.3	800	95	8.38
		5830	5	900	111	8.11
		6167	5.8	1000	129	7.77
		6964	8.4	1293	186	6.93
	25	2993	0.6	200	15	13.33
		3501	1.1	300	28	10.91
		4008	1.5	400	38	10.67
		4440	2	500	50	10.00
		4780	2.6	600	65	9.23
		5212	3.2	700	80	8.75
		5624	3.8	800	95	8.42
		5855	4.5	900	113	8.00
		6172	5.2	1000	130	7.69
		6738	6.8	1200	170	7.06
		7662	10.2	1580	255	6.20
EOLO CN13*5	22.2	2483	0.6	200	13	15.02	83℃
		2978	1	300	22	13.51
		3367	1.5	400	33	12.01
		3762	2	500	44	11.26
		4124	2.6	600	58	10.40
		4440	3.3	700	73	9.56
		4716	4	800	89	9.01
		4915	4.7	900	104	8.63
		5232	5.4	1000	120	8.34
		5757	7.05	1200	157	7.67
		6109	8.9	1400	198	7.09
		6704	11.2	1610	249	6.48
	25	2465	0.5	200	13	16.00
		2873	0.9	300	23	13.33
		3379	1.3	400	33	12.31
		3758	1.9	500	48	10.53
		4125	2.4	600	60	10.00
		4525	2.9	700	73	9.66
		4782	3.5	800	88	9.14
		5026	4.2	900	105	8.57
		5282	4.9	1000	123	8.16
		5760	6.4	1200	160	7.50
		6250	7.9	1400	198	7.09
		6621	9.8	1600	245	6.53
		7015	11.7	1800	293	6.15
		7283	13.1	1945	328	5.94
EOLO CN15*5.5	22.2	1915	0.5	200	11	18.02	100℃2min20s
		2358	0.8	300	18	16.89
		2656	1.3	400	29	13.86
		3040	1.8	500	40	12.51
		3267	2.3	600	51	11.75
		3482	2.9	700	64	10.87
		3716	3.5	800	78	10.30
		3920	4.2	900	93	9.65
		4131	4.9	1000	109	9.19
		4504	6.35	1200	141	8.51
		4816	8.15	1400	181	7.74
		5185	9.9	1600	220	7.28
		5450	12	1800	266	6.76
		6013	16.4	2210	364	6.07
	25	1932	0.4	200	10	20.00
		2333	0.8	300	20	15.00
		2679	1.2	400	30	13.33
		2992	1.55	500	39	12.90
		3281	2.1	600	53	11.43
		3460	2.6	700	65	10.77
		3726	3.1	800	78	10.32
		3926	3.7	900	93	9.73
		4166	4.4	1000	110	9.09
		4513	5.7	1200	143	8.42
		4868	7.2	1400	180	7.78
		5186	8.9	1600	223	7.19
		5469	10.7	1800	268	6.73
		5730	12.6	2000	315	6.35
		6035	14.8	2200	370	5.95
		6443	19.4	2651	485	5.47
EOLO CN17*6.2	14.8	1545	0.7	200	10	19.31	75℃
		1873	1.2	300	18	16.89
		2142	1.7	400	25	15.90
		2403	2.4	500	36	14.08
		2579	3.1	600	46	13.08
		2770	3.8	700	56	12.45
		2956	4.6	800	68	11.75
		3090	5.5	900	81	11.06
		3294	6.5	1000	96	10.40
		3548	8.5	1200	126	9.54
		3859	10.8	1400	160	8.76
		4078	13	1570	192	8.16
	16	1541	0.6	200	10	20.83
		1830	1.1	300	18	17.05
		2086	1.6	400	26	15.63
		2335	2.2	500	35	14.20
		2505	2.9	600	46	12.93
		2723	3.55	700	57	12.32
		2883	4.3	800	69	11.63
		2965	5.1	900	82	11.03
		3177	6	1000	96	10.42
		3548	7.9	1200	126	9.49
		3771	10.05	1400	161	8.71
		4058	12.5	1600	200	8.00
		4236	14.4	1770	230	7.68

V4008 600KV Test Reports:

Prop(inch)	Voltage(V)	RPM	Amps(A)	Thrust(gf)	Watts(W)	Efficiency(g/W)	Load temperature in 100% throttle
EOLO CN13*5	14.8	2511	1	200	15	13.51	75℃
		2960	1.6	300	24	12.67
		3429	2.4	400	36	11.26
		3808	3.3	500	49	10.24
		4188	4.2	600	62	9.65
		4440	5.3	700	78	8.92
		4757	6.3	800	93	8.58
		5046	7.35	900	109	8.27
		5317	8.5	1000	126	7.95
		5702	11.1	1200	164	7.30
		6505	16.4	1550	243	6.39
	16	2470	0.9	200	14	13.89
		2951	1.6	300	26	11.72
		3381	2.3	400	37	10.87
		3716	3	500	48	10.42
		4157	3.9	600	62	9.62
		4489	4.8	700	77	9.11
		4725	5.8	800	93	8.62
		5041	6.8	900	109	8.27
		5272	7.8	1000	125	8.01
		5817	10.2	1200	163	7.35
		6173	13	1400	208	6.73
		6916	18.3	1760	293	6.01
EOLO CN15*5.5	14.8	1931	0.8	200	12	16.89	85℃
		2337	1.4	300	21	14.48
		2725	2.1	400	31	12.87
		3025	2.9	500	43	11.65
		3258	3.7	600	55	10.96
		3535	4.6	700	68	10.28
		3741	5.6	800	83	9.65
		3972	6.6	900	98	9.21
		4133	7.6	1000	112	8.89
		4583	10.15	1200	150	7.99
		4846	12.9	1400	191	7.33
		5208	16.1	1600	238	6.71
		5456	19.5	1800	289	6.24
		5757	23.4	2029	346	5.86
	16	1950	0.8	200	13	15.63
		2358	1.3	300	21	14.42
		2706	2	400	32	12.50
		3002	2.7	500	43	11.57
		3306	3.4	600	54	11.03
		3562	4.3	700	69	10.17
		3776	5.3	800	85	9.43
		3915	6.2	900	99	9.07
		4260	7.15	1000	114	8.74
		4519	9.4	1200	150	7.98
		4865	12	1400	192	7.29
		5178	14.8	1600	237	6.76
		5466	18.6	1800	298	6.05
		5728	21.3	2000	341	5.87
		6048	26.2	2276	419	5.43
