Tarot 810 Sport FPV 6-Axis Hexacopter TL810S01 With Electric Retractable Landing Skid

:
TAROT 810SPORT multicopter is a multi-axis flight carrier designed for professional aerial photography, with standard new electric contraction folding landing gear, six-axle hub, head mount system, providing adequate installation space for al kinds of electronic systems , its lateral folding arm tcan bring the most powerful and stable support structure. It adopts 6 rotors to provide sufficient power, even if one of the axises unexpectedly stop working, it can also ensure the aircraft is in a stable condition. It is of lightweight, portable and convenient. The overall pure carbon cover adopts imported�0�2 3K Toray carbon fiber pure woven, with full CNC precision machining high temperature and pressure precast . Pure carbon matte twill carbon fiber quality beyond conventional commercial products, integrated performance beyond national standards for high-strength carbon fiber strip board a performance requirement.

Specifications:
Symmetric Motor Wheelbase: 810 MM
Rack Diameter: 920MM
Folding propeller Specifications: 15 inch
Arm length: 430MM
Center Cover specifications: 247 ¡Á 242 ¡Á 2.0MM
Motor mounting hole distance: 16MM / 19MM / 25MM / 27MM equilateral triangle-shaped mounting
Undercarriage clearance height: 362MM
Battery Specifications: 15C, 22.2V, 10000-2000MHA
6S Brushless ESC: 40A
Maximum power consumption: 4000W
Hover Power: 1500W
Working temperature: -10 ¡æ ~ 40 ¡æ
Net weight: 1.6KG
Total weight: 1.9KG
Flight load 3 kg, compressive load 15 kg

Recommended Configuration:
4114 / 320KV multi-axis brushless motor TL100B08
1555 carbon fiber multiaxial efficient reverse paddle TL2812
35-40A ESC multiaxial

Quick folding can be directly mounted line, safe, reliable, and can avoid the use of plug connection circuit. Patented design of the four locking folding mechanism allowing the machine arm steady as a rock.

The whole cover uses self-locking nut M3 PTZ panel in carbon fiber board, its structure using a unique design of thread self-locking screw technology, with excellent resistance to lateral vibration.

Quick folded portion innovately adopts �0�4 40 Falcon dovetail groove metal rivet , with a strong clamping force. Full carbon with excellent damping slip feel the tube collapsed.

Standard electric retractable tripod, bring unlimited broad aerial perspective.

The overall design�0�2 of lightweighted double color motor mount has strong perspective effect, providing a striking visual direction for the kit in the air. The new motor seat added new�0�2 Brushless ESC mounting position, the harness protection card, clip-on design can easily adjust motor base level.
